雙向差分壓力：

-25 .. 25 mbar --> -1000 .. 1000 mbar

差分壓力/相對壓力/表壓：

0 .. 50 mbar --> 0 .. 10000 mbar

絕對壓力：

0 .. 1000 mbar --> 0 .. 2000 mbar

      高精度小型化的壓力變送器AMS 3012系列，二線制電流輸出4..0mA，工作電壓范圍（8..36V）寬，經過校準和溫度補償（-25..85 °C），具有短路保護和極性反向保護功能。防塵防水等級（IP67），壓力連接端口是內螺紋M5，電氣連接是M5的專用接插座。金屬外殼，特別適合系統壓力高的差分壓力檢測。

主要參數

壓力范圍*	雙向差分壓力:	-25 .. 25 mbar --> -1000 .. 1000 mbar
	差分壓力/相對壓力/表壓:	0 .. 50 mbar --> 0 .. 10000 mbar
	絕對壓力:	0 .. 1000 mbar --> 0 .. 2000 mbar
	大氣壓力:	700 .. 1200 mbar
總誤差 (TEB)  (T = -25 °C .. 85 °C)	2.0 %FSO (max.)	低壓范圍 (≤ 100mbar)
	1.0 %FSO (max.)	標準壓力范圍 (> 100 mbar)
	1.0 %FSO (max.)	中等壓力范圍 (> 2000 mbar)
輸出電流	4..20 mA
工作電壓	8..36 V (典型 24 V)

Overview
AMS 3012 is a series of matchbox sized pressure transmitters with a 4 .. 20 mA current-loop output in a robust dust- and water-tight (IP67) metal package. The pressure ports are realized by two M5 female threads and the electrical connection by M5 circular sensor connector. The AMS 3012 are especially suitable for differential pressure measurement with large common-mode pressure. The transmitters with short circuit and reverse polarity protected output can be powered within a wide supply voltage range of 8 .. 36 V. All AMS 3012 are calibrated and temperature compensated in a range of -25 .. 85 °C and feature high accuracy at room temperature as well as a low overall error throughout the entire compensated temperature range.


Available Pressure Ranges
? Differential (relative) pressure: 0 .. 50 mbar up to 0 .. 10 bar
? Bidirectional differential pressure: -25 .. +25 mbar up to -1 .. +1 bar
? Absolut pressure: 0 .. 1 bar and 0 .. 2 bar
? Barometric pressure: 700 .. 1200 mbar
Custom specific pressure ranges or modifications are available on request


Typical Applications
? Industrial process control
? Medical instrumentation
? HVAC (Heating, Ventilation, Air Conditioning)
? Vacuum monitoring
? Pneumatic system monitoring
? Test benches
